Brazed Grooving Tools

     ● Available in MicroGrain ideal for most applications
     ● Specials of all types are also available made to your
        specifications.
Brazed Grooving Tools

For Grooving, Reliefs and O.D. Cutting.

Available in Right Angle (GR) or Straight (GS) Styles

Brazed Groove, Relief and OD Tools
GS GR Groove Corner DOC
Style Style Width Radius Max
GS-012002 GR-012002 .012/.014 .003 Max. .303
GS-012F GR-012F .012/.014 Full .030
GS-018002 GR-018002 .018/.020 .003 Max. .060
GS-018F GR-018F .018/.020 Full .060
GS-022002 GR-022002 .022/.024 .003 Max. .090
GS-022F GR-022F .022/.024 Full .090
GS-028002 GR-028002 .028/.030 .003 Max. .090
GS-028F GR-028F .028/.030 Full .090
GS-208002 GR-208002 .038/.040 .003 Max. .120
GS-038F GR-038F .038/.040 Full .120
GS-040002 GR-040002 .040/.042 .003 Max. .150
GS-040F GR-040F .040/.042 Full .150
GS-046002 GR-046-002 .046/.048 .003 Max. .150
GS-046F GR-046F .046/.048 Full .150
GS-054002 GR-054002 .054/.056 .003 Max. .180
GS-054F GR-054F .054/.056 Full .180
GS-060002 GR-060002 .060/.062 .003 Max. .210
GS-060F GR-060F .060/.062 Full .210
GS-068002 GR-068002 .068/.070 .003 Max. .210
GS-068F GR-068F .068/.070 Full .210
GS-072002 GR-072002 .072/.074 .003 Max. .240
GS-072F GR-072F .072/.074 Full .240
GS-080002 GR-080002 .080/.082 .003 Max. .270
GS-080F GR-080F .080/.082 Full .270
GS-086002 GR-086002 .086/.088 .003 Max. .270
GS-086F GR-086F .086/.088 Full .270
GS-090002 GR-09002 .090/.092 .003 Max. .300
GS-092F GR-092F .090/.092 Full .300
GS-096002 GR-096002 .096/.098 .003 Max. .300
GS-096F GR-096F .096/.098 Full .300
GS-102002 GR-102002 .102/.104 .003 Max. .400
GS-102F GR-102F .102/.104 Full .400
GS-114002 GR-114002 .114/.116 .003 Max. .400
GS-114F GR-114F .114/.116 Full .400
GS-120002 GR-120002 .120/.122 .003 Max. .400
GS-120F GR-120F .120/.122 Full .400
GS-122002 GR-122002 .122/.124 .003 Max. .400
GS-122F GR-122F .122/.124 Full .400
Grooving
